CLIP SGD Portable Single Gas Detector

LOREX Clip Single Gas Detectors SGD are designed for use in hazardous areas, and are available for hydrogen sulphide , carbon monoxide , or oxygen.

General Features

- Single Sensor O2, H2S, CO
- 2 Years Operational Life
- IP66/IP67 Protection Class
- UL, ATEX and CSA Certificate
- Visual Alarm LED
- 90 dB Audible Alarm - Vibration
- 30 Event Logs
- ATEX Certificate Ex 2GD Ex d IIC T6 Ex tD A21

Price : On Request -

Technical Specifications

Order Code / Name :	CL-H : Hydrogen Sulphide(0-100ppm) , CL-C : Carbon Monoxide(0-300ppm) , CL-O : Oxygen(0-30%Vol)
PC Interface :	RS232
Certificate :	UL-913 & CSA-C22.2 No.157 , Class 1 Div 1 & 2, Groups A, B, C and D , ATEX II 1G Ex ia IIC T4 Ga IECEx Ex ia IIC T4
Operational Life :	2 years > 2900 alarm minutes*
Compliance :	EMC Directive 2004/108/EC, FCC and IECES
Data Logging :	30 Event Log
Shelf Life :	6-month shelf life prior to activation shown on box label
Display :	Gaz Konsantrasyonunu Gösteren LCD Gösterge
Alarm Type :	90dB Audible Alarm/ Vibrating Alarm / Top, front and side visual LEDs
T90 Response :	10s
Weight :	93g (2.7oz) toxic, 104g (3.7oz) O2
Test :	Self test on activation and every 20hrs: continuous automatic battery integrity tests
Communication Accessories :	USB IR link for event download and configuration
Working Temperature :	H2S -40°C to + 50°C (-40°F to +122°F) / CO -40°C to + 50°C (-40°F to +122°F) / O2 -35°C to + 50°C (-31°F to +122°F)
Dimensions :	91 x 54 x 32mm (3.6 x 2.1 x 1.3ins)
