GAS-AA-A-001-G Portable LEL Single Gas Detector

Order Code , Description :	GAS-AA-A-001-G Portable LEL Explosive Gas Detector
PC Interface :	RS232
Operation standards :	EN50270, EN50271, IEC61508, EN61779, EN45544
Standards Safety :	EN60079-0, EN60079-11, EN60079-1, 94/9/EC
ATEX :	ATEX II 1G Ex ia IIC T4 Ga (-20°C ≤ Ta ≤ +65OC) BASEEFA04ATEX0384
Operating Time :	12 hours minimum for flammable unit
Battery :	Lithium battery for all gas types
Data Logging :	Full timed datalogging with adjustable sample rate, set to 1 min. data rate as default. 900 hours storage at 1 min. interval (54,000 logs), >4800 events
Display :	Custom LCD with backlight, with display of gas concentration. Graphic symbols for battery (with proportional indication of remaining operation time), and display mode. Start up indication when calibration is due within 30 days , calibration overdue or service required.
Audible Alarm :	95dB Multiple alarm options let you select distinctive tones for different alarm levels
Visible Alarm :	Dual colours red/ blue flashing LEDs in a gas hazard
Vibrating Alarm :	Internal vibrating alarm
Typical response times (T90) :	10s
Weight :	129g (4.6oz)
Working Temperature :	-20o C to + 65o C (-4o F to +149o F)
Dimensions :	90 x 48 x 24 mm (3.5 x 1.9 x 0.95 ins)
