Ei Electronics Ei605 Smoke Alarm
The Ei605 optical smoke alarm operates on the light scater principle to detect smoke particles entering the optical chamber. This optical alarm is sensitive to all domestic fire types but is especially sensitive to visible smouldering fires.
The Ei605 is supplied with screw fixings with simple to install twist on base. It is not possible to fit the alarm onto it’s mounting base if the battery is not present. The Alarm is fitted with a large easy to use Test Button to facilitate frequent testing of your Alarm. The Test button can also be used to silence nuissance alarms, e.g. cooking fumes, for a 10 minute period. The sounder will automatically stop sounding when smoke particles are no longer present in the chamber. The Ei605 will emit a short beep every 40 seconds to warn you that the battery needs replacing. The Ei605 will flash it’s red LED (light) evey 40 seconds to indicate that it has successfully conducted a self check of the alarm. There are also Hardwire and RadioLiNK interconnect versions available.
Detects all domestic fire types
High performance optical chamber
Battery included
Stand alone - no wiring required
Large easy to use Test Button
Silence nuisance / false alarms
Built in sounder - 85dB(A) at 3 metres
Low battery warning
VdS certified to EN14604:2005
5 Year guarantee
Technical Specification
| Model : Ei605 - Optical Smoke Detector | |
|---|---|
| Sensor Type : | Optical |
| Button Test : | Simulates the effect of smoke and checks chamber, electronics and horn |
| Supply Voltage : | 230VAC 50Hz |
| Battery : | 9V Replaceble |
| Alarm : | Electronic Piezo Siren |
| Self Test : | Smoke chamber is automatically tested every 40 seconds |
| Sound Level : | 85 dB(A) at 3 metres |
| Memory : | Red LED will flash twice every 40 seconds indicating recent Alarm event |
| Plastic Material : | UL94 HB |
| Operating Temperature : | Operating - 0°C to 40°C |
| Storage Temperature : | Storage - 0°C to 35°C (in a dry area) |
| Product Dimensions : | Product - 115mm x 50mm |
| Package Dimensions : | Package - 125mm x 125mm x 60mm |
| Weight : | 255g (Include Package) |
| Humidity : | 15% to 95% Relative Humidity |
